SC-Gcoms 1.25 interface USB 2.0 Long Exposure Digital Astronomical Telescope Eyepiece Camera

მახასიათებლები

Camera Specification
Sensor & Size(mm) Sony IMX224LQR 1/3"(4.8x3.6)
Pixel(um) 3.75x3.75
Dynamic range 2040mV with 01/30s
SNRmax 0.15mv with 1/30s
FPS/Resolution 27@1280x960 54@640x480
Binning 1x1, 2x2
Exposure 0.105ms~1000s

(FPS dependent on memory and speed of your computer. Using ROI function allows faster captured frame rates up to 60 fps)

OTHER HARDWARE CONFIGURATION
Spectral Range
350-1050nm with Double Side AR Coating Protect Window
(Optional: 405-690nm with IR-cut filter)
White Balance
ROI White Balance/ Manual Temp-Tint Adjustment
Color Rendering Technique
Ultra Fine Color Engine
Recording System
Still Picture and Movie
Guilding Port
ASCOM ST4-port
Cooling System*
Natural with High Performance Cooling Structure
OPERATING ENVIRONMENT
Operating Temperature -10C--50C
Storage Temperature -20C--60C
Operating Humidity 30~80%RH
Storage Humidity 10~60%RH
Power Supply
DC 5V over PC USB Port
SOFTWARE ENVIRONMENT
Operating System
Support Microsoft  Windows  XP / Vista / 7 /8/10 (32 & 64 bit)
OS X (Mac OS X), Linux
PC Requirements
CPU: Equal to Intel Core2 2.8GHz or Higher
Memory: 2GB or More
USB port: USB2.0 High-speed Port
Display: 17" or Larger
CD-ROM
